A continuous casting mold holds back liquid steel with nothing but a few millimeters of copper and a thin skin that solidifies on contact. Let that copper wear past its limit or let cooling turn uneven across the plate, and the risk isn't a quality defect, it's a breakout. This checklist covers what to verify on the copper plates, the cooling system, and the oscillation mechanism before a mold goes back into service. Sign up to turn this checklist into a guided digital procedure your crew follows on every changeout.
Few mm
Copper wall thickness standing between liquid steel and a breakout
Every Campaign
How often plate thickness should be measured before mold reuse
Zero Tolerance
Room for skipping a thickness check or reusing a plate below its limit
Every Micron
Level of precision cooling gap and coating checks need to hold
Why Mold Checks Happen Before Every Reuse
A mold copper plate looks the same after a hundred heats as it did after ten, right up until it doesn't. Thickness, coating condition, and cooling gap all wear gradually and invisibly, so measuring them before every reuse is what catches a plate that's quietly crossed its limit.
Copper Plate Condition
Copper Plate Wear & Taper Check
Inspect plate faces for uneven wear and confirm taper still matches the strand shrinkage profile
Plate Thickness Measurement
Measure remaining copper thickness at known hot-face wear points against the minimum reuse limit
Coating Condition Check
Check the plating layer for cracking or flaking that could increase friction and surface defects
Measure Every Plate Before It Goes Back In
Oxmaint guides your crew through thickness, coating, and cooling checks step by step, with readings logged against each mold plate across every campaign. Sign up for a free trial to build your mold inspection checklist, or book a demo to see it in action.
Cooling & Water Box Checks
Water Gap & Flow Distribution Check
Confirm the water gap is uniform and flow is even across the full plate width, not just at the center
Water Box Seal & Leak Check
Check water box seals and gaskets for leaks that could let cooling water reach the strand
Mold Cooling Water Temperature Check
Track inlet and outlet water temperature difference to confirm the mold is extracting heat as expected
Oscillation & Alignment Checks
Oscillation Stroke & Frequency Check
Verify oscillation stroke length and frequency match the cast schedule to avoid surface marks
Mold Level Sensor Check
Confirm the mold level sensor reads accurately, since a false reading can trigger a level control error
Mold Alignment & Squareness Check
Check mold plate alignment and squareness so the strand forms with consistent wall thickness
What A Skipped Check Can Cost You
| Check Skipped |
Likely Consequence |
| Plate thickness measurement |
A thinned plate is reused past its limit, raising breakout risk |
| Coating condition check |
Increased friction leads to surface defects or sticking on the strand |
| Water gap check |
Uneven cooling creates a hot spot on the shell, a leading breakout cause |
| Oscillation stroke check |
Visible oscillation marks or depressions along the strand surface |
Where A CMMS Fits Into Mold Checks
Oxmaint ties this checklist to each mold plate as a tracked asset, logging thickness readings and cast count across campaigns so a plate is pulled for reconditioning based on real wear data, not guesswork.
Frequently Asked Questions
Q
How often should mold copper plates be thickness-checked?
Plate thickness should be measured before every reuse, since copper wears gradually with each casting campaign and the surface can still look sound well after it's crossed its safe limit.
Q
What causes a breakout in continuous casting?
A breakout usually starts with uneven cooling or a thinned mold wall that lets a weak spot form in the solidifying shell, which then tears open once it's pulled below the mold.
Q
Can a CMMS track mold copper plate wear over multiple campaigns?
Yes, a CMMS can log thickness readings and cast counts against each specific plate, making it possible to compare wear rates across plates and plan reconditioning ahead of the limit.
